C9200L-24T-4X-E, Cisco Catalyst 9200L Switch, 24xGE, 4x10GE uplink, Network Essentials

Gambar besar : C9200L-24T-4X-E, Cisco Catalyst 9200L Switch, 24xGE, 4x10GE uplink, Network Essentials

Detail produk:

Tempat asal:	Cina
Nama merek:	Cisco
Sertifikasi:	CE
Nomor model:	C9200L-24T-4X-E

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	1
Waktu pengiriman:	2-3 hari
Syarat-syarat pembayaran:	T/T

Kontak

C9200L-24T-4X-E, Cisco Catalyst 9200L Switch, 24xGE, 4x10GE uplink, Network Essentials

Deskripsi

Nama Produk:	Mengalihkan	Nomor Bagian:	C9200L-24T-4X-E
Pembayaran:	TT	Pengiriman:	DHL
Kondisi:	Baru	Waktu Pimpin:	2-3 hari
Jaminan:	1 Tahun	Kata kunci:	-C9200L-24T-4X-E

Cisco C9200L-24T-4X-E Overview

Cisco C9200L-24T-4X-E is an enterprise-grade switch designed to deliver resilient layer 2/3 access for branch offices and midsize campus environments. As a pivotal member of the 9200 family, this Cisco solution enables advanced network control and security to protect critical business operations. Built around the C9200L-24T-4X-E architecture, network administrators benefit from 24 high-performance data ports, ensuring reliable connectivity for diverse devices and endpoints. Seamlessly integrating 4x 10G fixed uplinks, the C9200L-24T-4X-E enables high-capacity stacking and flexible expansion—an ideal fit for scalable infrastructures. Leveraging Cisco’s network essentials software, IT teams can employ intelligent segmentation, policy enforcement, and streamlined management across broad deployments, meeting evolving compliance and high-availability needs.

Figure 1 shows the front panel of C9200L-24T-4X-E.

Product Features Comparison

Model	C9200L-24T-4X-E	C9300-48UXM-E	C9200L-24PXG-4X-E	C9200L-48T-4X-E
Brand	Cisco	Cisco	Cisco	Cisco
Port Configuration	24 ports data, 4x 10G fixed uplinks	48, 4 x 10G SFP+	24 ports full PoE+ (8 mGig up to 10G, 16 ports up to 1G), 4x 10G fixed uplinks	48 ports data, 4x 10G fixed uplinks
Switching Capacity	128 Gbps	480 Gbps	272 Gbps	176 Gbps
Forwarding Rate	190.4 Mpps	360 Mpps	214.28 Mpps	261.9 Mpps
PoE Budget	n/a	n/a	Up to 600W (implied by power supply, exact PoE budget not explicitly stated)	n/a
Stacking Capability	80 Gbps	n/a	80 Gbps	80 Gbps

Optional Add-ons

Model Number	Description
PWR-C5-125WAC	Cisco 125W AC power supply, compatible with C9200L series switches, provides reliable core power.
C9200L-STACK-KIT	Cisco stacking kit for C9200L series, enables high bandwidth stacking functionality.
GLC-LH-SMD	Cisco SFP transceiver module, Gigabit Ethernet long-range optical for uplink expansion.

Cisco C9200L-24T-4X-E Specification

Model

C9200L-24T-4X-E

Brand

Cisco

Downlinks total 10/100/1000 or PoE+ copper ports

24 ports data

Uplink configuration

4x 10G fixed uplinks

Default primary AC power supply

PWR-C5-125WAC

Fans

Fixed redundant

Software

Network Essentials

Chassis Dimensions

1.73 x 17.5 x 11.3 in / 4.4 x 44.5 x 28.8 cm

Virtual Networks

Stacking bandwidth

80 Gbps

Total number of MAC addresses

16,000

Total number of IPv4 routes (ARP plus learned routes)

11,000 (8,000 direct routes and 3,000 indirect routes)

IPv4 routing entries

3,000

IPv6 routing entries

1,500

Multicast routing scale

1,000

QoS scale entries

1,000

ACL scale entries

1,500

Packet buffer per SKU

6 MB buffers for 24- or 48-port Gigabit Ethernet models

Flexible NetFlow (FNF) entries

16,000 flows on 24- and 48-port Gigabit Ethernet models

DRAM

2 GB

Flash

4 GB

VLAN IDs

1024

Total Switched Virtual Interfaces (SVIs)

512

Jumbo frames

9198 bytes

Switching capacity

128 Gbps

Forwarding rate

190.4 Mpps

Mean time between failures (hours)

525,990

Weight

3.5 kg
